Square D 8501XO30V02 110/120 VAC 10/5 Amp 3-Pole 3NO Panel Mount AC Operated Control Relay

Product Description

The Square D 8501XO30V02 is a control relay designed for operation at 110/120 VAC. It has a current rating of ten amperes and features three normally open contacts. This relay is ideal for various applications requiring long life and reliability.

• Rated for 600 VAC with a ten ampere resistive current rating.
• Includes three plug-in contact cartridges for easy replacement and maintenance.
• UL listed and CSA certified for safety and quality.

Product Highlights

This relay is suitable for demanding applications. Its modular design offers convenience. Work is simplified with straight-through wiring.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: 8501XO30V02
• Mounting Type: Panel
• Coil Voltage: 110 V AC 50 Hz; 120 V AC 60 Hz
• Current Rating: 10 A AC; 5 A DC
• Number of Poles: 3
• Contact Configuration: 3 NO standard contact cartridges
• Operating Temperature: -40 to 160 degrees F
• Height: 3.5 in
• Width: 2.23 in
• Depth: 3.95 in
