Square D 2601BW1 600 VAC 7.5 Hp NEMA 4 Reversing Drum Switch

Product Description

The Square D 2601BW1 is a reversing drum switch designed for operating motors directly across the line. This switch allows for reversing control of both AC and DC motors, making it suitable for a variety of applications. The NEMA 4 enclosure ensures protection against dust and water, enabling reliable performance in challenging environments. This model is UL listed and CSA certified, ensuring it meets rigorous industry standards.

• Designed for squirrel cage and single-phase motors
• Field convertible from maintained to momentary operation
• Durable NEMA 4 enclosure with dimensions of six point eight nine inches tall, four point four inches wide, and five point five inches deep

Product Highlights

Reliable motor control with easy installation and strong environmental protection.

Product Information

Standard Information

• Catalog Number: 2601BW1
• Brand: Square D

Technical Specifications

• Type: Reversing Drum Switch
• Voltage: 250 Volt
• Actuator: Standard one-piece
• Enclosure Rating: NEMA 4
• Horsepower Ratings: 1.5 hp at 115 Volt AC, 3 hp at 230 Volt AC, 5 hp at 460 Volt AC, 7.5 hp at 575 Volt AC
• Number of Poles: 3 Pole
• Country of Origin: Mexico
• Warranty Length: eighteen months
