Square D 2601AW2 Reversing Drum Switch 600 Vac Nema 4

Product Description

The SQUARE D 2601AW2 is a reversing drum switch rated for operation at up to 600 VAC and 250 VDC input voltage. Drum switches provide manual control of motor direction by routing power through a set of contacts arranged on a rotating drum mechanism. This unit is built to a NEMA 4 enclosure rating, making it suitable for environments where washdown or moisture exposure is a concern. It is installed by licensed electricians and motor control technicians in industrial and commercial applications where manual motor reversing is required. The switch meets CSA, RoHS, and UL Listed standards.

The 2601AW2 is used in applications that require direct manual control over the rotational direction of single-phase or three-phase motors. Typical installations include lathes, drill presses, hoists, conveyors, and other machinery where an operator needs to reverse motor direction at the point of use. The NEMA 4 rating makes it a fit for light industrial environments, outdoor enclosures, and areas subject to splashing water or dust. It is a replacement-grade component suitable for restoring original manual reversing function on existing motor control setups.

Key Features

• Reversing operation type for manual motor direction control
• 600 VAC input voltage rating for broad compatibility with standard industrial supply voltages
• 250 VDC input voltage rating for DC motor applications
• NEMA 4 enclosure rating provides resistance to splashing water and windblown dust
• UL Listed and CSA certified for code-compliant installations
• RoHS compliant construction

Compatibility

Designed as an OEM-style replacement reversing drum switch for industrial motor control applications requiring manual direction switching at rated voltage levels.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements for motor control and disconnecting means. De-energize the circuit and lock out and tag out the supply voltage before removing or installing the switch. Verify that the supply voltage and motor ratings fall within the switch contact ratings before energizing. Do not exceed the rated voltage or current capacity of the drum switch contacts.
