Sprecher & Schuh L8-40/3/C L8 Series Circuit Breaker 40A CURVE-C 3-Pole

Product Description

The SPRECHER & SCHUH L8-40/3/C Series L8 Supplemental Protectors provide overcurrent protection for control circuits, solenoids, actuators, appliances, and business equipment. Suitable for applications up to 480V AC and 96V DC. They are ideal for use in equipment installed throughout the world and are DIN rail mountable.

• Color coded status indicator
• Broad range of currents
• Interrupting capacities up to 10 kA

Product Highlights

The SPRECHER & SCHUH L8-40/3/C supplemental protectors are UL Recognized, CSA, and CE approved.

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: L8-40/3/C

Technical Specifications

• Series: Series L8 Supplemental Protectors
• Applications: up to 480V AC and 96V DC
• Curve: B, C & D
• Protection: IP20 protection against accidental contact
• Approvals: UL Recognized, UL1077, CSA 22.2 No.235, IEC 60947-2, CE marked
• Brand: Sprecher + Schuh
• Manufacturer Part Number: L8-40/3/C
• Category: Molded Case Circuit Breaker
• Manufacturer: Sprecher + Schuh
• Product Series: L8
• Family Series: Sprecher + Schuh Circuit Breakers, L8 Series
• Description: CB 40A CURVE-C 3-POLE
• Poles: 3
• Current Rating: 40 A
• Max Voltage: 480 VAC
• Trip Curve: C
• Trip Unit: Thermal Magnetic
• Electronic Trip Unit: No
• Mounting: DIN Rail
• Neutral Pole: No
• GFCI: No
• 100% Rated: No
• Terminal Type: Screw
• Auxiliary Switch: Optional
• Shunt Trip: Optional
• Undervoltage Release: No
• Alarm Switch: No
• UL Standard: 1077
• MPN: L8-40/3/C
