Sprecher & Schuh L8-25/3/C Miniature Circuit Breakers 25A

Product Description

The Sprecher & Schuh L8-25/3/C miniature circuit breaker is a supplementary protector with CURVE-C and 25A, designed with 3 poles. It adheres to UL1077, NFPA79, CSA, and CE standards. Ideal for DIN Rail mounting, this circuit breaker provides thermal magnetic trip unit and screw terminals.

• 25A current rating
• 3-Pole configuration
• DIN Rail mounting

Product Highlights

The Sprecher & Schuh L8-25/3/C is a reliable choice for circuit protection needs.

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: L8-25/3/C

Technical Specifications

• Brand: Sprecher & Schuh
• Part Number #: L8-25/3/C
• SKU #: 2126628
• UNSPSC: 39121603
• Category: Molded Case Circuit Breaker
• Manufacturer Part Number: L8-25/3/C
• Manufacturer: Sprecher + Schuh
• Product Series: L8
• Family Series: Sprecher + Schuh Circuit Breakers, L8 Series
• Description: CB 25A CURVE-C 3-POLE
• Poles: 3
• Current Rating: 25 A
• Max Voltage: 480 VAC
• Trip Curve: C
• Trip Unit: Thermal Magnetic
• Electronic Trip Unit: No
• Mounting: DIN Rail
• Neutral Pole: No
• GFCI: No
• 100% Rated: No
• Terminal Type: Screw
• Auxiliary Switch: Optional
• Shunt Trip: Optional
• Undervoltage Release: No
• Alarm Switch: No
• UL Standard: 1077
• Approvals: CE, CSA, IEC, UL, UR
• MPN: L8-25/3/C
• Manufacturers: Sprecher & Schuh
• Sub-Category: Molded Case
• Primary brand: Sprecher+Schuh
• Order code / Manufacturer SKU: L8-25/3/C
• Manufacturer product status: Commercialized
• Manufacturer description: S+S L8 Suppl. Protector 3 Pole - CB 25A CURVE-C 3-POLE
