Sprecher & Schuh L8-15/1/C Miniature Circuit Breaker 15 AMP

Product Description

The Sprecher & Schuh L8-15/1/C is a single pole 15 AMP miniature supplementary circuit breaker with C trip curve rating. Effective where medium levels on inrush are expected, most times in applications that include lighting, transformers, pilot devices, coils and control circuits. Rated up to 277 volt AC / 48 volt DC at 10kA.

• Visual trip indicator
• Mounts on standard DIN Rail
• On/off toggle switch

Product Highlights

The L8-15/1/C circuit breaker has a visual trip indicator, mounts on standard DIN Rail and comes with a on/off toggle switch. Screw terminals are provided for easy installation.

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: L8-15/1/C

Technical Specifications

• AMP Rating: 15 A
• Number of Poles: 1
• Trip Curve: C
• Mounting: DIN Rail
• Manufacturer Part Number: L8-15/1/C
• Manufacturer: Sprecher + Schuh
• Product Series: L8
• Family Series: Sprecher + Schuh Circuit Breakers, L8 Series
• Description: CB 15A CURVE-C 1-POLE
• Current Rating: 15 A
• Max Voltage: 277 VAC
• Trip Unit: Thermal Magnetic
• Electronic Trip Unit: No
• Neutral Pole: No
• GFCI: No
• 100% Rated: No
• Terminal Type: Screw
• Auxiliary Switch: Optional
• Shunt Trip: Optional
• Undervoltage Release: No
• Alarm Switch: No
• UL Standard: 1077
• Approvals: CE, CSA, IEC, UL, UR
• Ampere Rating: 15 A
• Poles: 1 Pole
• All - Voltage: 277VAC/48VDC
• Circuit Breaker Type: UL1077
• Short Circuit Capacity: 10kA
• Series: L8 Series
