Sprecher & Schuh L8-10/3/C Protector 10A 3-Pole

Product Description

The SPRECHER & SCHUH L8-10/3/C series supplementary protectors provide overcurrent protection for control circuits, solenoids, actuators, appliances, business equipment, and other applications requiring current limiting. They feature advanced design and global approvals for worldwide use. Available with Type B, C, and D tripping characteristics, defining the response speed to overcurrent levels.

• Applications up to 480V AC and 96V DC
• Color coded status indicator
• UL1077 supplemental short circuit protection for industrial applications up to 63 amps.

Product Highlights

The L8-10/3/C supplementary protectors are ideal for equipment installed globally.

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: L8-10/3/C
• Country of Origin: United States

Technical Specifications

• Applications: up to 480V AC and 96V DC
• Curve: B, C & D
• Protection: IP20 protection against accidental contact
• Status indicator: Color coded status indicator
• Currents: Broad range of currents
• Interrupting capacities: up to 10 kA
• Mounting: DIN rail mountable
• UL: UL Recognized, UL1077
• CSA: CSA 22.2 No.235
• IEC: IEC 60947-2
• CE: CE marked
• Brand: Sprecher & Schuh
• Part Number #: L8-10/3/C
• SKU #: 2259057
• Series: L8
• Manufacturer Name: Sprecher + Schuh
• UNSPSC: 39121603
• MPN: L8-10/3/C
• Country of Origin: United States
• Condition: New – Open box
• IP Rating: IP20 protection against accidental contact
• Current Range: Broad range of currents
• Interrupting Capacity: up to 10 kA
• Certification: CE marked
• Amps: 10A
• Poles: 3 Pole
• Trip Characteristic: C
• Number of Poles: 3
