Sprecher & Schuh L8-1/3/C Supplementary Protectors CURVE-C 1A 3P UL1077/ NFPA79/ CSA/ CE

Product Description

The Sprecher & Schuh L8-1/3/C supplementary protectors provide overcurrent protection for control circuits, solenoids, actuators, appliances, business equipment, and other applications requiring a high-performance current limiting device. They are ideal for use in equipment installed worldwide. Available with Type ", B, C & D tripping characteristics, defining the device’s trip-time to overcurrent levels.

• UL 1077 Supplementary Protectors for Use in Appliances or Electrical Equipment
• CSA 22.2 No. 235 Supplementary Standard
• For use in the United States in accordance with NFPA 79 (NEC).
• CE Certified IEC 60947-2 Mini Circuit Breaker Standard

Product Highlights

Supplementary protectors for overcurrent protection in various applications with global certifications.

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: L8-1/3/C

Technical Specifications

• UNSPSC Code: 39120000
• Brand: Sprecher + Schuh
• Manufacturer Part Number: L8-1/3/C
• Unit of Measure: EA
• MPN: L81/3/C
• Primary brand: Sprecher+Schuh
• Order code / Manufacturer SKU: L8-1/3/C
• Manufacturer product status: Commercialized
• Manufacturer description: S+S L8 Suppl. Protector 3 Pole - CB 1A CURVE-C 3-POLE
• Applications: up to 480V AC and 96V DC
• Curve: B, C & D
• IP Rating: IP20 protection against accidental contact
• Status indicator: Color coded status indicator
• Current range: Broad range of currents
• Interrupting capacities: up to 10 kA
• Mounting: DIN rail mountable
• UL: UL Recognized, UL1077
• CSA: CSA 22.2 No.235
• IEC: IEC 60947-2
• Certification: CE marked
