Sprecher & Schuh L11-J60-1753 Disconnect Switch 60A (3-Pole Open Type)

Product Description

Sprecher & Schuh L11-J60-1753 is a fused UL98 disconnect switch rated 60 A with Class J fuse holders in a 3-pole open type configuration. The unit supports AC voltages up to 600 VAC and DC up to 250 VDC, is suitable for service entrance and motor control applications, and can be mounted on a base or DIN rail. The model is supplied with a handle shaft and conforms to multiple international standards.

• Fusible 3-pole disconnect with Class J fuse holders; current rating 60 A and UL98 classification
• Voltage ratings: 600 VAC and 250 VDC; mounting options include base or DIN; supplied with handle shaft
• Compact dimensions 4-29/64 in H x 5-19/32 in W x 4-31/64 in D; operating temperature range -22 to 55°C (open)

Product Highlights

Fused 3-pole UL98 disconnect switch, 60 A, Class J fuses, open type, base/DIN mounting

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: L11-J60-1753

Technical Specifications

• Brand: Sprecher & Schuh
• Manufacturer: Sprecher + Schuh
• Manufacturer Part Number: L11-J60-1753
• Alternate Part Number: PN-547327
• Series: L11
• Product Series: L11
• Description: Disconnect Switch, Class J Fuses, 60A, 3-Pole, Open Type, UL98
• Function: UL98 Disconnect Switch
• Type: Fusible Disconnect Switch
• Fuse Class: Class J
• Fusible: Yes
• Number of Poles: 3
• Current Rating: 60 A
• AC Voltage Rating: 600 VAC
• DC Voltage Rating: 250 VDC
• Mounting: Base, DIN
• Enclosure Type: Open Type
• Enclosed: No
• Housing Material: Polycarbonate
• Dimensions: 4-29/64 in H x 5-19/32 in W x 4-31/64 in D
• Net Weight: 2.48 lbs
• Horsepower Range: 1.5 to 50 hp
• Temperature Rating: -22 to 55 °C (Open)
• Handle Shaft: Supplied
• Mounting Hardware Included: Yes (for 30A and 60A models)
• SKU: 2228550
• UPC: 00886739427895
• UNSPSC: 39122233
• Application: Service entrance, motor control and electrical protection
• Standards/Approvals: IEC 60947-4-1 / EN 60947-3, BS EN 60947-3, VDE 0660, CSA 22.2 No. 4, NEMA KS-1, UL 98, ASTA, LOVAG, CE, NFPA 79
• Certifications: CE, CSA, UL
