Sprecher & Schuh KT9-PE1-10 Auxiliary Contact 4 A Front Mount 1NO 1-Pole (Pack 1)

Product Description

Sprecher & Schuh KT9-PE1-10 is a front-mount auxiliary contact for KT9 series motor protection circuit breakers. It provides one normally open (1NO) contact in a single-pole configuration and is rated 4 A at up to 250 VAC for signaling and interlocking with KT9 devices. The accessory mounts directly to KT9 motor starters and thermal-magnetic breakers to extend control and indication functions.

• Front-mount auxiliary contact, 1 normally open (1NO), single-pole configuration
• Electrical rating: 4 A output current, maximum 250 VAC
• Designed for use with KT9 series breakers; approvals include CCC, CE, cULus

Product Highlights

Front-mount 1NO auxiliary contact for KT9 series, rated 4 A / 250 VAC, pack quantity 1

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: KT9-PE1-10

Technical Specifications

• Brand: Sprecher & Schuh
• Manufacturer Part Number: KT9-PE1-10
• SKU: KT9-PE1-10
• Product Type: Auxiliary Contact (Front Mount)
• Series: KT9
• Contact Configuration: 1 NO (normally open)
• Poles: 1-Pole
• Mounting Type: Front mount
• Compatible With: KT9 series breakers
• Current Rating: 4 A
• Max Voltage: 250 VAC
• Approvals: CCC, CE, cULus
• Weight: 0.10 lb
• Package Quantity: 1
• UPC: 00191326880053
• UNSPSC: 39121522
