Sprecher & Schuh CS7-PV-02 Auxiliary Contact Front Mount 2NC 2-Pole

Product Description

Sprecher & Schuh CS7-PV-02 is an auxiliary contact module for CS7 contactors providing a front-mount 2NC (two normally closed) configuration in a 2-pole assembly. It fits as a top/front auxiliary block with terminal positions 51-52 and 61-62 and is designed for snap-on mounting without tools. Contact options include electronic-compatible standard contacts rated to 17 V, 5 mA and a bifurcated version rated to 5 V, 3 mA.

• Front/top mount auxiliary contact, 2NC (two normally closed), 2-pole; terminals 51-52 and 61-62
• Snap-on design for tool-free attachment to CS7 series contactors
• Electronic-compatible standard contacts rated to 17 V, 5 mA; bifurcated option rated to 5 V, 3 mA

Product Highlights

Front/top mount 2NC auxiliary contact for CS7 series; snap-on installation; terminals 51-52 and 61-62.

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: CS7-PV-02

Technical Specifications

• Brand: Sprecher & Schuh
• Manufacturer Part Number: CS7-PV-02
• Catalog Description: CS7 Auxiliary Contact Front Mount 2NC 2-Pole
• Mounting Type: Front / Top mount
• Mounting Method: Snap-on (tool-free)
• Number of Poles: 2
• Contact Configuration: 2 NC (two normally closed)
• Terminal Positions: 51-52, 61-62
• Series: CS7 Series
• Electronic Compatibility: Standard contacts down to 17 V, 5 mA
• Bifurcated Contact Rating: 5 V, 3 mA
• Mechanical Linkage: Linked between N.O. and N.C. poles and to control relay poles
• SKU: 2259762
• UNSPSC: 39121522
• UPC: 00886739485864
• Unit of Measure: EA
