Sprecher & Schuh CA7-9E-01-24E IEC contactor 9 A (3 pole) 22-301-307-94

Product Description

Sprecher & Schuh CA7-9E-01-24E is a CA7 series IEC contactor with a 24 V DC coil and three power poles. It provides AC-3 switching at 9 A and AC-1 capability of 32 A, and includes one normally closed auxiliary contact (1 NC). The contactor features mechanically linked force-guided contacts per IEC 60947-5-1, screw terminations, and approvals including CCC, CSA, and cULus, intended for compact motor control applications.

• Three-pole CA7 IEC contactor with 24 V DC coil and one normally closed auxiliary contact (1 NC).
• Electrical ratings: AC-3 9 A, AC-1 32 A; CA7 series frame coverage up to 75 HP at 460/575 V.
• Mechanically linked (force-guided) contacts meeting IEC 60947-5-1, screw termination, approvals CCC, CSA, cULus; compatible with CEP7 overload relays and KT9 controllers.

Product Highlights

3-pole CA7 IEC contactor, 9 A AC-3, 24 V DC coil, 1 NC auxiliary; approvals CCC, CSA, cULus.

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: CA7-9E-01-24E

Technical Specifications

• Brand: Sprecher & Schuh
• Manufacturer Part Number: CA7-9E-01-24E
• Alternate Part Number: 22-301-307-94
• Series: CA7
• Product Type: IEC Contactor
• Type: AC Non-Reversing IEC
• Number of Poles: 3
• Coil Voltage: 24 V DC
• Coil Type: Non latching
• Auxiliary Contacts: 1 NC
• Termination: Screw
• Current (AC-1): 32 A
• Current (AC-3): 9 A
• Frame Size: CA7
• Frame Series HP Coverage: Up to 75 HP @ 460/575 V
• Compatibility: Compatible with Sprecher + Schuh CEP7 electronic overload relays and KT9 motor circuit controllers
• Approvals/Certifications: CCC, CSA, cULus
• Net Weight: 0.875 lbs
• Gross Weight: 0.9 lbs
• UNSPSC Code: 39120000
