Sprecher and Schuh CS7-PV-40 Auxiliary Contact Block 10 A (4-Pole)

Product Description

Sprecher and Schuh CS7-PV-40 is an auxiliary contact block for CS7 series contactors and motor starters, providing a front-mount auxiliary contact assembly with four normally open contacts. The module is a 4-pole configuration rated for 10 A at up to 690 V and supports top-mount auxiliary positions (reference contacts 64, 73-74, 83-84). It is used to add auxiliary switching functionality to contactors and starters.

• Front-mount auxiliary contact block compatible with top-mount positions
• Four normally open contacts (4 NO) in a 4-pole arrangement
• Rated 10 A current and 690 V voltage for control and auxiliary circuits

Product Highlights

Front-mount auxiliary contact block; 4 NO contacts; 4-pole; rated 10 A, 690 V; compatible with CS7 contactors and motor starters

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: CS7-PV-40

Technical Specifications

• Brand: Sprecher and Schuh
• Manufacturer Part Number: CS7-PV-40
• Catalog Description: CS7 Auxiliary Contact Front Mount 4NO 4-Pole
• Contact Configuration: 4 NO (4 normally open)
• Number of Contacts: 4
• Number of Poles: 4
• Rated Current: 10 Amps
• Voltage Rating: 690 V
• Mounting Type: Front mount (top-mount compatible)
• Intended Application: Auxiliary contact block for motor starters and contactors
• Additional Contact References: 64, 73-74, 83-84
• Unit Count: 1.0 Count
