Sprecher and Schuh CA7-43-10-24Z Contactor 43 A (3 Pole)

Product Description

Sprecher and Schuh CA7-43-10-24Z is a 3-pole contactor with a 24 V coil rated for 43 A, used for motor and load switching in industrial control and automation systems. It supports 50/60 Hz operation and includes one normally open auxiliary contact. The CA7 family is designed and tested for Type 1 and Type 2 short-circuit coordination and features mechanically linked (positively/force guided) contacts, modular accessories, reversible coil connections, and dual power terminals on larger frames.

• Rated current 43 A, 3 poles, coil voltage 24 V, frequency 50/60 Hz
• Normally open main contacts with 1 auxiliary contact; mechanically linked (positively/force guided) contacts
• Family-level features: Type 1 and Type 2 short-circuit coordination, modular interchangeable accessories, reversible coil connections, dual power terminals on larger frames

Product Highlights

3-pole 43 A contactor with 24 V coil, NO auxiliary contact, Type 1/2 short-circuit coordination, modular accessories

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: CA7-43-10-24Z

Technical Specifications

• Manufacturer Part Number: CA7-43-10-24Z
• Brand: Sprecher and Schuh
• Series: CA7
• Product Type: Contactor
• Rated Current: 43 A
• Number of Poles: 3
• Coil Voltage: 24 V
• Frequency: 50 Hz / 60 Hz
• Contact Configuration: NO (Normally Open)
• Number of Auxiliary Contacts: 1
• Short-Circuit Coordination: Type 1 and Type 2
• Contact Mechanism: Mechanically linked (positively/force guided)
• Dual Power Terminals: Yes (on CA7-30 through CA7-97)
• Reversible Coil Connections: Yes
• Modular Accessories: Interchangeable across CA7 line
• Maximum Horsepower (family): Up to 75 HP @ 460/575 V (family-level rating, not necessarily this exact model)
