Sporlan 901180 Evaporator Pressure Regulating Valve 7/8 ODF ORIT-6-30/100

Product Description

The Sporlan 901180 Evaporator Pressure Regulating Valve is designed for use in refrigeration systems. This valve type is known as ORIT-6-30/100. It is made for connections with seven-eighths inch outer diameter flare. This valve opens upon an increase of inlet pressure, making it effective for controlling pressure in evaporator systems.

• Type ORIT-6/-10 Direct Acting Adjustable
• Maximum fluid temperature: 240 degrees Fahrenheit
• UL Listed and CSA Certified

Product Highlights

This product features hermetic construction, ensuring durability in various environments. It comes standard with an inlet strainer on ODF models, enhancing its functionality in keeping the fluid clean.

Product Information

Standard Information

• Brand: Sporlan
• Part Number: 901180

Technical Specifications

• Size: 7/8
• Type: Valve
• Connection Ends: 7/8 ODF
• Pressure Rating: 30 to 100 psig
• Port Size: 3/4
• Length: 10.5 inches
• Width: 6.4 inches
• Height: 1.6 inches
