Sporlan 806526 SPORLAN SER-A TXV Valve

Product Description

The Sporlan SER-A TXV Valve 806526 is a thermal expansion valve designed for precise control using a step motor. This design enhances the valve's capability to manage refrigerant flow efficiently.

• Step motor operation ensures accurate control.
• Compatible with HCFC, HFC refrigerants, and oils, including subcritical CO2.
• ODF connection with a three-eighths inch inlet and half-inch outlet.

Product Highlights

This valve is built with corrosion-resistant and self-lubricating materials, which prolong its service life. It operates efficiently under a maximum rated pressure of one thousand fifteen psig and a maximum operating differential pressure of five hundred eighty psid.

Product Information

Standard Information

• OEM: Sporlan
• Vendor Name: Sporlan

Technical Specifications

• OEM #: 806526
• Connection Size Inlet: 3/8 inches
• Connection Size Outlet: 1/2 inches
• Connection Type: ODF
• Maximum Rated Pressure: 1015 psig
• MOPD: 580 psid
• Overall Height: 6.4 inches
• Operating Temperature: -50 to 155 degrees Fahrenheit
