Sporlan 800006 Suction Filter, 1-1/8 ODF w/ Relief Bi-Directional SF-289-T

Product Description

The Sporlan 800006 suction filter is designed to protect compressors from contaminants in refrigeration systems. This model features a one and one-eighth inch ODF connection and provides bi-directional flow. Its bypass relief feature prevents system shutdowns in case the filter-drier becomes plugged.

• Protects compressor from contaminants
• Compatible with all brazing alloys
• Bypass feature ensures operation during filter blockage

Product Highlights

Efficient flow design minimizes pressure drops and enhances system reliability in refrigeration applications.

Product Information

Standard Information

• Brand: Sporlan
• Part Number: 800006

Technical Specifications

• Size: 1-1/8 inches
• Length: 11.5 inches
• Width: 3.3 inches
• Height: 3.3 inches
• Capacity: 28 cu in
• Diameter: 3.00 inches
• Connection Ends: ODF
• Master Product Group: Contaminant Control Products
• Product Group: Sealed Filter-Driers
• Item Class: SEALED SUC FLTR
• Harmonized Code: 8421.39.8090
