Sporlan 770906 O Z/L PZK-CP14-HNBR 7/8 OD End Cap

Product Description

The SPORLAN 770906 O Z/L PZK-CP14-HNBR End Cap is a flame-free, dome head copper fitting with a 7/8 inch nominal size and ZoomLock end connection. Designed for high-pressure HVAC/R systems, glycol, and non-potable water, it features a 700 PSI pressure rating and 250 Deg F temperature rating. This cap is not suitable for R22 refrigerant and is compatible with various ZoomLock components, providing secure, braze-free connections.

• Flame-Free installation method
• Huge Labour and Time Saving
• More Repeatable than Brazing

Product Highlights

This copper end cap provides a secure, flame-free connection for HVAC/R systems, reducing installation time and labor, but is not for R22 refrigerant.

Product Information

Standard Information

• Brand: SPORLAN
• Manufacturer Part Number: 770906
• Country of Origin: USA

Technical Specifications

• Type: Flame-Free, Dome Head
• Material: Copper
• Nominal Size: 7/8 Inch
• Series/Model: PZK
• End Connection: ZoomLock
• Pressure Rating: 700 PSI
• Temperature Rating: 250 Deg F
• Application: High Pressure HVAC/R System, Glycol, Non-Potable Water
• Applicable Standard: UL (Canada and US), UL 207/109, ASHRAE-15, ANSI 15/31.5, ASME B31.5, ICC-ES, PMG-1296, IMC, IRC, UMC
• Minimum Burst Pressure: 2100 PSI
• O-Ring Material: HNBR
• Vacuum Pressure Capability: 20 Micron
• Compatibility: ODM x ODM ZoomLock Ball Valve/Filter Drier/Moisture and Liquid Indicator/Solenoid Valve
• Material Specification: ASTM B75/B743
