Sporlan 761201 Filter-Drier ZoomLock Catch-All C-164-PZK 1/2 Inch ODF Liquid Line

Product Description

The SPORLAN 761201 Filter-Drier, a ZoomLock Catch-All C-164-PZK sealed liquid line model, provides contaminant control in HVAC&R systems. It effectively captures moisture, acids, and solid debris, ensuring the longevity and efficiency of air conditioning and refrigeration systems. This 1/2 inch solder connection filter drier operates with a 650 psig pressure rating and supports HFC, HFO, HC, and HCFC refrigerants, suitable for systems with a 3 to 6 ton flow capacity.

• Complete contaminant control to protect and extend system life and ensure system reliability.
• High performance desiccant package provides high water capacity and acid capacity.
• Porous molded replaceable core provides excellent filtration of solid debris for TEV and compressor protection.

Product Highlights

Ensures system reliability by controlling moisture, acids, and solid debris with a high-performance desiccant and porous core.

Product Information

Standard Information

• Brand: SPORLAN
• Manufacturer Part Number: 761201

Technical Specifications

• MPN: 761201
• SKU: 761201
• Brand: Sporlan
• Part Number: 761201
• Series: Spring Stocking
• Core: 16 cu-in
• Connection Type: Solder
• Finish: Epoxy Powder-Coated
• Flow Capacity: 3 to 6 ton
• Pressure Rating: 650 psig
• Refrigerant Type: HFC, HFO, HC, HCFC
• Surface Area: 33 sq-in
• Temperature Rating: -40 to 66 deg C
• Type: Filter-Drier
• Connection: 1/2 inch ODF Liquid Line
• Model/Series: ZoomLock Catch-All C-164-PZK
