Sporlan 401432 c305hh catchall filter drier 2 to 10 ton 5/8 sae 30 cu-in

Product Description

The Sporlan 401432 is a sealed, charcoal style core liquid line filter drier for air conditioning and refrigeration. It features a 3 inch diameter, 10.19 inch length, 1/4 inch SAE flare end connection, and 30 cubic inch desiccant volume. Compatible with R22, R134A, R407C, R404A, R410A, R507 refrigerants, it offers 2 to 10 ton capacity. With a 650 PSI pressure rating and -40 to 66 degrees C temperature range, it suits residential, commercial HVAC, and food service applications.

• Ensures decontamination and cleaning of circuits polluted by moisture, dirt, acid, wax, or sludge.
• Offers high capacity for acid retention, moisture adsorption, and trapping sludge and wax.
• Utilizes a special blend of molecular sieve, activated alumina, and activated charcoal in molded cores.

Product Highlights

RoHS compliant, UL listed, and suitable for diverse HVAC, refrigeration, and food service applications.

Product Information

Standard Information

• Brand: SPORLAN
• Manufacturer Part Number: 401432
• Country of Origin: USA

Technical Specifications

• RoHS Compliant: Yes
• Refrigerant Type: R22/R134A/R407C/R404A/R410A/R507
• End Connection: 1/4 Inch SAE Flare x 1/4 Inch SAE Flare
• Volume of Desiccant: 30 Cubic Inch
• Capacity: 2 to 10 Ton
• Filter Area: 53 Square Inch
• Pressure Rating: 650 PSI
• Temperature Rating: -40 to 66 °C
• Application: Residential and Commercial HVAC, Food Service, Specialty and Ultra-Low Temperature, Transportation
• Certifications: UL (Canada and US), REACH, ATEX, PED
• Product Type: Filter Drier
• Line Type: Liquid Line
• Core Style: Sealed, Charcoal
• Model Number: C-305-HH
• Series: HH
• Used On: Air Conditioner and Refrigeration
• MPN: 401432
• Brand: Sporlan
• Manufacturer: PARKER HANNIFIN CORP
• Connection Style: SAE Flare
