Spirax Sarco 62815 B5 Inverted Bucket Steam Trap

Product Description

The Spirax Sarco B5 Inverted Bucket Steam Trap, MPN 62815, uses an inverted bucket mechanism. This mechanism responds to the density difference between steam and condensate for effective operation. The trap discharges condensate close to steam temperature, ensuring efficient performance.

• Operates with a maximum pressure of thirty psig.
• Constructed from durable cast iron for longevity.
• Designed for in-line horizontal piping configurations.

Product Highlights

The Spirax Sarco B5 Inverted Bucket Steam Trap is reliable for various steam applications. It allows steam to enter from one side while discharging condensate on the opposite side. This design enhances its ability to vent air and non-condensable gases efficiently.

Product Information

Standard Information

• Brand: Spirax Sarco
• Manufacturer: Spirax-Sarco Inc

Technical Specifications

• Steam Trap Type: Inverted Bucket
• Nominal Size: Two inches
• Pressure Rating: Thirty psig
• Temperature Rating: Four hundred fifty degrees Fahrenheit
• Length: Eleven point two inches
• Material: Cast Iron
• End Style: FNPT
• Series: B Series
• Weight: Seventy-five pounds
