Spirax Sarco 3397315 M10S ISO Ball Valve

Product Description

The Spirax Sarco M10S ISO ball valve, MPN 3397315, is a three-piece body valve designed for steam and industrial fluids. It operates effectively in both low and high-temperature environments. The valve can be serviced without being removed from piping, ensuring minimal downtime.

• Lever operated actuator designed for easy operation
• Durable stainless steel ball and carbon steel body
• Reduced bore port for efficient media flow

Product Highlights

This valve is built for reliability in various applications, especially for steam and fluid control.

Product Information

Standard Information

• Manufacturer: Spirax-Sarco Inc
• Brand: Spirax Sarco

Technical Specifications

• Actuator Type: Lever Operated
• Ball Material: Stainless Steel
• Body Material: Carbon Steel
• End Style: NPT
• Finish: Zinc Plated
• Inlet to Outlet Length: 2.68 in
• Media: Fluid/Steam
• Nominal Size: 3/4 in
• Port Type: Reduced Bore
• Pressure Rating: 1500 psig
• Temperature Rating: 445 deg F
• Top to Inlet Center: 2.72 in
• Trim Material: Stainless Steel Stem and RPTFE Seat
