Spirax Sarco 1465600 UFT32-21 Universal Ball Float and Thermostatic Steam Trap

Product Description

The Spirax Sarco 1465600 UFT32-21 is a universal ball float and thermostatic steam trap with an integral automatic air venting facility. Designed for differential steam pressures up to 32 bar, the UFT32 is constructed from austenitic stainless steel and is maintenance free. Pipeline connectors are available with screwed, socket weld, and flanged end connections.

• Ball Float and Thermostatic Steam Trap
• Maintenance free sealed
• Integral automatic air venting facility

Product Highlights

Universal steam trap designed for steam pressures up to 32 bar and easy replacement with minimal system downtime.

Product Information

Standard Information

• Brand: SPIRAX SARCO
• Manufacturer Part Number: 1465600

Technical Specifications

• Length: 168.5 mm
• Material: 304 Stainless Steel
• Pressure Rating: 32 bar g
• Series: UFT32-21
• Temperature Rating: 0 to 286 deg C
• Type: Universal
• Brand: SPIRAX SARCO
• End Style: Universal Connector
• Max Operating Pressure: 21 bar
• Max Allowable Pressure: 50 barg
• Max Allowable Temperature: 400 deg C
• Application: For pipeline connectors
• Standards and Approvals: ASME Class 300 | ASME Section IX and BS/EN 288 | ASTM A351 Grade CF8 | EN 10204 3.1/10213-4 1.4308 | European Pressure Equipment Directive
• MPN: 1465600
• Category: Steam Trap
