Spirax-Sarco 1201150 - 6 Flanged Cast Iron Steam Control Valve

Product Description

Spirax-Sarco offers the 1201150 steam control valve, designed for managing pressure and temperature in various applications. This valve features a six-inch NPT connection and a maximum operating pressure of 250 psi. It is compatible with 25P pressure, 25T temperature pilots, or other actuated pilots. When ordering, provide specific details for the pilot type, pressure range, temperature range, and any necessary capillary connections.

• Applications include steam control in heaters and exchangers.
• Reduces steam pressure from supply to operational needs.
• Constructed with durable cast iron for long-lasting use.

Product Highlights

This valve is reliable for maintaining consistent steam pressure and temperature across systems. It is designed for various configurations, allowing for seamless integration into existing systems.

Product Information

Standard Information

• Brand: Spirax-Sarco
• MPN: 1201150

Technical Specifications

• Model: 25
• Valve Size: 6 inches
• Valve Connection: Flanged
• Piping Configuration: Straight
• Body Material: Cast Iron
• Valve Application: Steam
• Max Pressure: 125 psi WSP
• Weight: 518.00 lbs
