Spi Z9627SS Test Indicator Height Gage Bar 3 Inches

Product Description

The SPI Z9627SS is a test indicator height gage bar designed for use with dial and digital test indicators in precision measurement setups. Measuring 3 inches in overall length, this bar provides a stable, accurate mounting surface for positioning test indicators at the correct height during inspection or surface plate work. It fits any clamp that accepts a 0.25-inch-thick by 0.5-inch-height bar, making it a versatile accessory for metrology and quality control applications. Machinists, QC technicians, and tool room professionals install this bar as part of a height gage or surface inspection fixture assembly.

This height gage bar is suited for use on surface plates, CMM setups, and production floor inspection stations where consistent test indicator positioning is required. It is compatible with any standard clamp designed to accept the 0.25-inch-thick by 0.5-inch-height bar profile, a widely used dimension across many indicator holder and gage stand systems. Typical use cases include part runout checks, flatness inspection, and height transfer measurements in both shop and lab environments.

Key Features

• 3-inch overall length for flexible indicator positioning height
• Fits all clamps accepting a 0.25-inch-thick by 0.5-inch-height bar profile
• Designed for use with dial and digital test indicator setups
• Compact form factor suits surface plate and fixture-based inspection work
• Sold individually for targeted replacement or expansion of existing gage setups

Compatibility

Compatible with all clamps that accept a 0.25-inch-thick by 0.5-inch-height bar. This is a widely standardized bar profile used across many indicator holder systems and gage stands.

Installation Notes

Installation is performed by metrology or tool room personnel. Insert the bar into any compatible clamp and secure the clamp fastener to the manufacturer-specified snug fit without over-torquing. Ensure the surface plate or mounting fixture is clean and free of burrs before assembly to avoid measurement error. No special tools or trade licenses are required for installation of this accessory.
