Spi 14-196-0 Telescoping Gage 1-1/4 to 2-1/8 in

Product Description

The SPI 14-196-0 is a telescoping gage used to measure inside diameters, bores, and slots with a range of 1-1/4 to 2-1/8 inches. The tool extends to contact the bore wall, locks in place, and is then measured with an outside micrometer to obtain the diameter. Overall length is 5.85 inches with a 5-inch handle. The working faces are TiN coated for wear resistance, and the body is finished in satin chrome. Built from hardened tool steel, this gage is suited for machinists, tool-and-die workers, and precision measurement applications in shop or field environments.

This telescoping gage is appropriate for use in general machining, engine rebuilding, hydraulic cylinder inspection, and any application requiring accurate inside-diameter measurement in the 1-1/4 to 2-1/8 inch range. The compact overall length of 5.85 inches makes it practical for use in moderately deep bores. It is a hand-measurement instrument intended for technicians and tradespeople who require repeatable inside-diameter readings without a dedicated bore gauge setup.

Key Features

• Measuring range: 1-1/4 to 2-1/8 inches
• 5.85-inch overall length with a 5-inch handle for controlled feel in the bore
• TiN coated working faces resist wear and extend service life
• Hardened tool steel construction for durability under repeated use
• Satin chrome finish reduces glare and resists corrosion
• Locks in the expanded position for accurate transfer to an outside micrometer

Compatibility

Designed as a general-purpose telescoping gage for inside-diameter measurement in applications requiring a range of 1-1/4 to 2-1/8 inches; intended for use with a standard outside micrometer to obtain final measurements.

Installation Notes

No power source or installation is required for this hand measurement tool. Compress the gage, insert it into the bore at a slight angle, allow it to expand against the bore wall, then lock and withdraw carefully for transfer measurement. Always use a calibrated outside micrometer when taking the final reading. Keep working faces clean and free of debris to maintain measurement accuracy.
