Spi 13-311-6 Pin Gage Handle M0 Aluminum

Product Description

The SPI 13-311-6 is an aluminum pin gage handle sized for M0 gage pins, designed to hold and manipulate precision pin gages during inspection and measurement tasks. The handle accepts pin gages in the 0.011 to 0.06 inch ring diameter range, making it suited for very fine tolerance work at the small end of the pin gage spectrum. Weighing just 0.022 pounds and measuring 4.22 inches in length, the 13-311-6 is compact and easy to handle in tight inspection environments. Machinists, quality control technicians, and tool room personnel use this handle as standard equipment alongside go/no-go gage sets.

This pin gage handle is used in manufacturing, machining, and quality assurance environments where small-bore hole diameters must be verified to close tolerances. It is appropriate for both shop floor and inspection room use. The M0 handle size corresponds to the smallest standard handle class, intended specifically for the finest diameter pin gages. It is a single-piece handle sold individually.

Key Features

• M0 handle size accommodates pin gages from 0.011 to 0.06 inches in ring diameter
• Aluminum construction keeps the handle lightweight at 0.022 pounds
• Compact form factor at 4.22 inches long and 0.5 inches wide for easy use in confined spaces
• Designed for precision measurement and inspection applications
• Sold as a single unit with a minimum order quantity of one

Compatibility

Designed as an OEM-style replacement or direct-use handle compatible with M0 class pin gages in the 0.011 to 0.06 inch ring diameter range.

Installation Notes

Pin gage handles are installed and used by machinists, quality technicians, and metrologists without special tools. Insert the appropriate pin gage into the handle collet and tighten according to the gage pin set instructions before use. Handle pin gages with care to avoid dropping or applying lateral force, which can bend fine-diameter pins and affect measurement accuracy. Store gage pins in their original case when not in use to prevent damage.
