Speco VID2412CONV 24VAC to 12VDC 500ma Voltage Regulator

Product Description

The SPECO VID2412CONV is a compact voltage regulator that converts 24VAC input to a regulated 12VDC output at up to 500mA. It is designed for use in CCTV and video surveillance installations where cameras or associated equipment require a stable 12VDC supply but only 24VAC power is available at the installation point. This regulator bridges the gap between common building automation and access control power infrastructure and the DC requirements of modern surveillance cameras. Licensed security installers and low-voltage technicians are the primary trades that specify and install this device.

The VID2412CONV is suited for commercial and residential CCTV installations where a centralized 24VAC transformer feeds multiple devices and individual cameras need regulated 12VDC at the head end or at the camera location. It is a single-unit, one-per-package component typically installed at the camera drop or within an enclosure near the power source.

Key Features

• Converts 24VAC input to regulated 12VDC output
• 500mA output current capacity supports typical analog and IP camera loads
• Designed for CCTV and video surveillance power applications
• Single-unit packaging simplifies per-drop installation

Compatibility

Designed as an OEM-style voltage regulator for CCTV power supply applications requiring 24VAC to 12VDC conversion in surveillance system installations.

Installation Notes

Installation should be performed by a licensed low-voltage or security systems technician in accordance with applicable NEC low-voltage wiring requirements. De-energize the 24VAC power source before making any wiring connections to the regulator. Verify that the total current draw of connected equipment does not exceed the 500mA rated output to prevent overloading the device.
