SPECIALTY PRODUCTS OBFS-8020-LL Firestop Ice Maker Box with CPVC Valves

Product Description

The SPECIALTY PRODUCTS OBFS-8020-LL is a firestop ice maker box designed with CPVC valves. This product combines condensate, drain, and supply connections into one unit. It features replaceable valves that include a triple O-ring seal for improved reliability.

• Integrates condensate, drain, and supply lines in one box.
• Replaceable valves with a triple O-ring seal.
• Includes a 2-inch drain connection rated up to 40 psi.

Product Highlights

This ice maker box is suitable for installation in stud bays and can be mounted side by side with other boxes. It is designed to meet fire safety standards, making it an essential choice for ice maker installations in various settings.

Product Information

Standard Information

• Brand: SPECIALTY PRODUCTS
• MPN: OBFS-8020-LL

Technical Specifications

• Model: OBFS-8020-LL
• Type: Ice Maker Box
• Applications: Suitable for wood or metal studs
• Certification: Warnock Hersey certified to ASTM E-814
• Dimensions: 5-11/16 inches x 3-7/8 inches x 2-5/8 inches
• Faceplate Size: 5-1/4 inches x 7-1/4 inches
• Features: Quarter turn ball valve
