Spears 819-007c Cpvc Sch 80 45 Deg Elbow Fpt X Fpt 3/4 in

Product Description

The SPEARS 819-007c is a 3/4 inch CPVC Schedule 80 45-degree elbow with female pipe thread (FPT) connections on both ends. This fitting is designed to change flow direction by 45 degrees in threaded CPVC piping systems. Schedule 80 CPVC offers a heavier wall thickness than Schedule 40, making it suitable for higher-pressure applications and corrosive fluid handling. Plumbers and pipefitters install this fitting in hot and cold water distribution, chemical process lines, and industrial fluid systems where the superior chemical resistance of CPVC is required.

This elbow is used in residential and commercial plumbing and industrial piping applications where a moderate directional change is needed without a full 90-degree turn. The FPT x FPT configuration threads onto male-threaded pipe or fittings on both sides. It is commonly installed in chemical handling systems, water treatment facilities, and industrial process lines where CPVC material provides an advantage over metal or standard PVC fittings.

Key Features

• Schedule 80 wall thickness for higher pressure ratings compared to Schedule 40
• CPVC construction provides excellent resistance to corrosive fluids and elevated temperatures
• 45-degree angle allows gradual directional changes with lower flow restriction than a 90-degree elbow
• FPT x FPT ends accept standard male-threaded pipe on both sides
• 3/4 inch fitting size suits common residential and light commercial pipe runs

Compatibility

Designed as an OEM-style replacement or new-installation fitting for Schedule 80 CPVC threaded piping systems using 3/4 inch pipe.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and ASTM standards for CPVC piping. Shut off and depressurize the system fully before removing any existing fittings. Use CPVC-compatible thread sealant or PTFE tape rated for CPVC on all threaded connections. Do not use petroleum-based solvents or incompatible pipe dopes, as these can degrade CPVC material.

Technical Specifications

• Fitting Material: CPVC
• Fitting Size: 3/4 inches
• Connection Type: FPT x FPT
• Schedule/Class: Schedule 80
• Item Weight: 0.07 pounds

Standard Information

• Brand: SPEARS
• Manufacturer Part Number: 819-007c
