SPEARS 7080401 Bronze Ball Valve - 3/4 FNPT x MNPT

Product Description

The SPEARS 7080401 is a bronze ball valve made with a two-piece construction. This valve features female NPT on one side and male NPT on the other side, both sized at three quarters of an inch. It is designed to handle steam media and operates within a temperature range from minus twenty degrees Fahrenheit to four hundred twenty-five degrees Fahrenheit. This product can withstand a maximum pressure of six hundred psi for CWP and one hundred fifty psi for steam.

• Constructed from bronze with a brass stem
• Lever handle enables easy manual operation
• Meets several compliance standards including ASTM B584-C84400

Product Highlights

The ball valve is suitable for applications involving steam, providing reliable flow control and system integrity.

Product Information

Standard Information

• Body Material: Bronze
• Valve Series: 70

Technical Specifications

• Item: Ball Valve
• Port Style: Standard Port
• Connection Type: FNPT x MNPT
• Maximum Operating Pressure: 600 psi
• Media Type: Steam
• Temperature Range: -20°F to 425°F
• Handle Type: Lever
• Connections: 3/4 Inch
