SPEARS 7010404 Bronze Ball Valve with 3/4 Inch NPT and 2-1/4 Inch Extension

Product Description

The SPEARS 7010404 is a ball valve made of bronze with a brass ball. It has a three-quarter inch NPT connection and a two and one-fourth inch stem extension. This valve is appropriate for various applications requiring durability and reliability.

• Bronze body and brass ball for longevity.
• Works effectively in temperatures from -20 degrees Fahrenheit to 500 degrees Fahrenheit.
• 2-part housing for simplicity in installation and maintenance.

Product Highlights

This product is designed for a wide range of applications, handling high pressures and temperatures.

Product Information

Standard Information

• Brand: SPEARS
• MPN: 7010404

Technical Specifications

• Item: Ball Valve
• Body Material: Bronze
• Ball Material: Brass
• Connection Type: FNPT
• Size: 3/4 inch
• Max. Pressure: 600 psi
• Maximum Temperature: 500 degrees Fahrenheit
• Minimum Temperature: -20 degrees Fahrenheit
• Temperature Range: -28.89 degrees Celsius to +260 degrees Celsius
• Housing Construction: 2-Part
• Shape: Straight
• Stem Size: 2 1/4 inch
• Series: 70 Series
• Dimensions: 7.45 x 2.76 x 4.43 inches
• Weight: 1.73 lbs
