Spears 54211849057 Pvc Plug 3/4 in Spigot Sch 80 150 Psi

Product Description

The SPEARS 54211849057 is a 3/4-inch nominal PVC plug fitting rated for Schedule 80/XH service in pressurized piping systems. Injection molded from PVC Type I, cell classification 12454, this spigot-end plug delivers a pressure rating of 150 psi non-shock at 73 degrees F. At 1.25 inches in length and just 0.04 pounds, it installs quickly as a termination point in dead-end runs or capped branch lines. Licensed plumbers and pipefitters specify this fitting where chemical resistance, gray PVC construction, and NSF-certified potable water compliance are required.

This plug is suited for residential and light commercial plumbing, irrigation, and industrial piping installations where PVC SCH 80/XH fittings are specified. The spigot end style allows direct insertion into a socket-end fitting or valve. Typical applications include capping unused ports on manifolds, terminating branch lines, and pressure-testing piping segments. Domestic manufacture supports project specifications requiring US-origin materials.

Key Features

• SCH 80/XH pressure rating at 150 psi non-shock at 73 degrees F
• PVC Type I, cell classification 12454 per ASTM D1784
• NSF-certified for potable water service
• Injection molded construction per ASTM D2467
• Spigot end style for standard socket connections
• Domestic manufacture, country of origin: United States

Compatibility

Designed as an OEM-style replacement and standard component for PVC SCH 80/XH piping systems using 3/4-inch spigot-to-socket connections conforming to ASTM D2467.

Installation Notes

Installation is performed by licensed plumbers or pipefitters. Depressurize and drain the line completely before removing or installing any fitting. Solvent-cement the spigot end into a compatible SCH 80 socket using a PVC-rated primer and cement per the fitting manufacturer and local plumbing code requirements. Do not exceed the 150 psi non-shock pressure rating or the 73 degrees F temperature rating for full pressure service.

Technical Specifications

• Fitting Type: Plug
• Nominal Size: 3/4 inches
• End Style: Spigot
• Schedule Rating: SCH 80/XH
• Pressure Rating: 150 psi non-shock
• Temperature Rating: 73 degrees F
• Length: 1.25 inches
• Material: PVC Type I, Cell Classification 12454
• Color: Gray
• Method of Manufacture: Injection Molded
• Weight: 0.04 pounds
• Standards and Approvals: ANSI B16.5, ASTM D1784, ASTM D2467, NSF Approved
• Country of Origin: United States

Standard Information

• Brand: SPEARS
• Manufacturer Part Number: 54211849057
