Spears 416-007 PVC Elbow 22-1/2 Degree Slip 3/4 inch SCH40

Product Description

The Spears 416-007 is a robust 22-1/2 degree elbow fitting designed for optimal performance in a variety of plumbing applications. Known for its high-quality standards, Spears ensures this elbow fitting adheres to rigorous manufacturing protocols.

• Exceptional durability with chemical and corrosion resistance.
• Supports high temperature applications up to 140 degrees Fahrenheit.
• Designed for ease of installation, resulting in lower installation costs and higher flow capacity.

Product Highlights

This PVC elbow is engineered for efficiency, integrating seamlessly into both domestic and commercial piping systems. It allows for a smooth change in direction, minimizing pressure loss and maximizing flow dynamics.

Product Information

Standard Information

• Color: White
• Material: PVC
• Connection Type: Slip x Slip
• Operating Temperature: Up to 140 degrees Fahrenheit

Technical Specifications

• Nominal Size: 3/4 inch
• Schedule Rating: SCH 40
• Application: Potable Water System
• Standards Met: ASTM D1784, ANSI NSF 61
