Spears 3639-007 3/4 PVC TU2K STDBV SOC/FPT FKM

Product Description

The Spears 3639-007 is a 3/4 inch PVC True Union 2000 Standard Ball Valve designed for various plumbing applications. This valve features socket and FNPT ends for secure connections, making it suitable for both residential and commercial installations.

• Pressure rated to 235 psi for reliable performance.
• Constructed from durable PVC with FKM softgoods.
• Self-adjusting floating seat enhances sealing capability.

Product Highlights

Designed to ensure high reliability in fluid control systems, this ball valve meets industry standards and can be utilized for potable water applications.

Product Information

Standard Information

• Manufacturer: Spears
• Model Number: 3639-007

Technical Specifications

• Nominal Size: 3/4 inch
• Body Material: PVC
• Ball Material: PVC
• O-Ring Material: FKM
• Pressure Rating: 235 psi
• Temperature Rating: 140 degrees F
• Inlet to Outlet Length: 4-13/16 inches
• Top to Inlet Center: 1-31/32 inches
• Actuator Type: T-Handle
• Domestic/Import: Domestic
• End Style: Socket and FNPT
• Series: True Union 2000
