Spears 3631-030C 3 CPVC TU2K Standard BV THD FKM

Product Description

Spears Ball Valve, model 3631-030C is a three-inch CPVC true union ball valve designed for fluid control in various piping systems. This valve features threaded ends, a durable CPVC construction, and is rated for pressures up to one hundred fifty psi. It operates at temperatures up to two hundred degrees Fahrenheit. The ball valve also incorporates a T-handle actuator for easy operation.

• Type: True Union 2000
• Pressure Rating: 150 psi
• Temperature Rating: 200 deg F

Product Highlights

This valve is ideal for applications requiring reliable flow control. The self-adjusting floating seat enhances sealing capabilities while the FKM O-ring ensures compatibility with various fluids.

Product Information

Standard Information

• Manufacturer: Spears
• MPN: 3631-030C

Technical Specifications

• Nominal Size: 3 in
• Body Material: CPVC
• Ball Material: CPVC
• Trim Material: CPVC Stem and PTFE Seat
• Actuator Type: T-Handle
• End Style: FNPT
• Inlet to Outlet Length: 9-7/8 in
• Top to Inlet Center: 5-7/8 in
• Softgoods Material: FKM
• Domestic/Import: Domestic
