Spears 3629-005C 1/2 CPVC TU2K STANDARD BV SOC/FPT EPDM

Product Description

The Spears 3629-005C is a 1/2 inch CPVC true union ball valve suitable for socket and FNPT connections. This valve is reliable, designed for both high pressure and temperature applications. The valve operates at a pressure rating of two hundred thirty-five psi and a temperature rating of two hundred degrees Fahrenheit.

• True union design allows easy maintenance and replacement.
• EPDM seals are NSF approved for potable water use.
• Features a T-handle actuator for simple operation.

Product Highlights

This ball valve is ideal for use in plumbing and industrial applications. It ensures a tight seal and easy flow control for various fluid management systems.

Product Information

Standard Information

• Material: CPVC
• Type: Standard Ball Valve

Technical Specifications

• MPN: 3629-005C
• Nominal Size: 1/2 inch
• Pressure Rating: 235 psi
• Temperature Rating: 200 degrees Fahrenheit
• Length: 4-3/16 inches
• Top to Inlet Center: 1-5/8 inches
• Softgoods Material: EPDM
• Body Material: CPVC
