Honeywell BZE6-2RN80 Enclosed Limit Switch 15A Snap Action Microswitch

Product Description

The Honeywell BZE6-2RN80 is a robust and reliable enclosed limit switch designed for demanding applications. This microswitch features a top roller plunger actuator and offers SPDT snap action. Its durable design and efficient operation make it suitable for a wide range of industrial environments.

• Operating voltage ranges between 125/250/480/600 VAC and 125/250 VDC.
• Features a contact rating of 1/2 A at 125 VAC.
• Constructed with die cast zinc and an epoxy coating for enhanced durability and resistance.

Product Highlights

This limit switch is capable of handling up to 15 amperes of current, making it ideal for medium-duty applications. Its compact size allows for installation in constrained spaces without compromising operational integrity.

Product Information

Technical Specifications

• Product Type: Enclosed Limit Switch
• Actuator: Top Roller Plunger
• Contact Configuration: SPDT
• Enclosure Rating: NEMA 1/3/4/IP66
• Dimensions: 77.2 mm L x 25.4 mm W x 44.4 mm H
• Operating Cycles: 5,000,000 Cycles
• Operating Temperature: -32 to 71 degrees Celsius
• Material: Die Cast Zinc, Epoxy Coated
