SPA PARTS 275-3123-00 Thermostat - 12 Inch Capillary, 1/4 Inch Bulb

Product Description

The SPA PARTS 275-3123-00 is a standard thermostat designed for effective temperature regulation in pool applications. This thermostat has a single pole single throw (SPST) configuration and connects using a 2-pin connection.

• Temperature range between 59°F to 104°F.
• Includes a 12-inch capillary tube for remote temperature sensing.
• Rated for 25A at 110V and 220V applications.

Product Highlights

The SPA PARTS 275-3123-00 thermostat is ideal for ensuring the correct temperature in pool systems, maintaining optimal performance and safety.

Product Information

Standard Information

• Type: Standard
• Bulb Diameter: 1/4 inch

Technical Specifications

• Cable Length: 12 inches
• Bulb Length: 3.4 inches
• Capillary Length: 12 inches
• Thermostat Amperage: 25A
• Electrical Connection: Slide Connector, 1/4 Male
• Pole/Throw: Single Pole Single Throw (SPST)
• Rated: 25A 110/220V
• Connection: 2-Pin
• Temperature Range: 59°F to 104°F
• Dimension (Approx.) Length: 2.1 inches
• Dimension (Approx.) Height: 1.73 inches
• Dimension (Approx.) Width: 0.905 inches
