Spa Electrics r10al12r1gmp Retro Led Pool Light 45W

Product Description

The SPA ELECTRICS r10al12r1gmp is a multi-color LED retrofit lighting kit engineered to upgrade existing 10-inch underwater pool niches to modern, high-efficiency LED performance. Running on 10.5 to 13 volts AC and drawing 45 watts, this fixture delivers 3200 lumens through an RGB+W LED array, producing a full Multi-Plus color spectrum including white. The kit includes a 10-inch Aqualumin adapter, plug and seal assembly, and a grey rim — everything a pool technician needs to complete a clean, drop-in niche replacement. Rated IPX8 for continuous submersion, it is built specifically for permanent underwater installation in residential and commercial pool environments.

This kit is designed for retrofit installation into standard 10-inch concrete and vinyl pool niches with an interior diameter ranging from 9.05 to 9.6 inches. The included adapter, seal assembly, and grey rim make it a complete solution for pool service professionals replacing aging incandescent or halogen fixtures. The RGB+W array supports dynamic color-changing modes as well as static white output, making it suitable for both decorative and functional pool lighting applications. Installation is typically performed by a licensed pool or electrical contractor.

Key Features

• 45W RGB+W LED array delivers 3200 lumens of underwater output
• Multi-Plus color capability spanning full RGB spectrum plus dedicated white channel
• IPX8-rated for continuous submersion in pool environments
• Fits 10-inch concrete and vinyl niches with interior diameters from 9.05 to 9.6 inches
• Complete kit includes Aqualumin adapter, plug and seal assembly, and grey rim
• Low-voltage AC operation at 10.5 to 13 volts for compatibility with standard pool lighting transformers

Compatibility

Designed for retrofit installation into standard 10-inch underwater pool niches, both concrete and vinyl construction, with an interior diameter of 9.05 to 9.6 inches. Requires a low-voltage AC supply in the 10.5 to 13 volt range.

Installation Notes

Installation must be performed by a licensed electrician or qualified pool service professional in accordance with local electrical codes and applicable NEC requirements for underwater pool lighting. Always de-energize the pool lighting circuit at the breaker and verify the circuit is de-energized before handling any underwater fixture or wiring. Ensure the niche interior diameter falls within the 9.05 to 9.6 inch specified range before beginning the retrofit. Verify all gaskets and seals are properly seated before returning the fixture to service.

Technical Specifications

• Voltage: 10.5 to 13 volts AC
• Wattage: 45W
• Lumens: 3200 lm
• LED Array: RGB+W
• LED Color: Multi-Plus
• Ingress Protection: IPX8
• Suitable Niche Size: 10 inches (ID 9.05 to 9.6 inches)
• Niche Type: Concrete and Vinyl

Standard Information

• Brand: SPA ELECTRICS
• Manufacturer Part Number: r10al12r1gmp
