Spa Electrics Q6C L12 L3 CMP is a 6" Quantum Series underwater LED pool light for concrete pools that operates at 12 V AC and consumes 12 W. It uses a high-intensity ceramic light engine and is rated IPX8 for submersion. The unit includes a concrete mounting kit with 100 ft or 150 ft cable options and requires a 12V AC UL-listed transformer. (UL certified.)
Ceramic high-intensity LED light engine providing multi-color Multi-Plus (RGB+W) or single-color options
Operates at 12 V AC, 12 W power consumption, IPX8 submersible rating and UL certified
Includes concrete mounting kit and 100 ft or 150 ft cable options; requires 12V AC UL-listed transformer
Product Highlights
6" concrete pool LED fixture, IPX8 submersible, 12V AC 12W operation, includes concrete mounting kit
Product Information
Standard Information
Brand: SPA ELECTRICS
Manufacturer Part Number: Q6C L12 L3 CMP
Country of Origin: Australia
Technical Specifications
Brand
Spa Electrics
Manufacturer Part Number
Q6C L12 L3 CMP
Series
Quantum 6" WN-Series
Application
Concrete pools
Light source
Ceramic light engine (LED)
LED type
Multi-Plus (RGB+W); also available in Blue, White, Red
Input Voltage
12 V AC
Operating Voltage Range
10.5-13 V AC
Wattage
12 W
Lumens
Approximately 850 lm (manufacturer-listed for Multi-Plus)
IP rating
IPX8
Certification
UL certified
Country of manufacture
Australia
Mounting type
Concrete mounting kit included
Cable length
100 ft or 150 ft (depending on SKU)
Compatibility
Wall-switch operation and major pool automation systems including Hayward Omnilogic, Pentair IntelliTouch/EasyTouch, Zodiac/Jandy
Transformer requirement
Requires 12V AC UL-listed transformer (LVX series recommended)
Ambient operating temperature
41�F to 104�F
Includes
Concrete mounting kit; 100 ft or 150 ft cable (depending on SKU)
