Southwire W8301 Orange Wire Connector

Product Description

The SOUTHWIRE W8301 is an orange wire connector designed for making secure, insulated electrical splices in residential and commercial wiring applications. Wire connectors of this type twist onto stripped conductor ends, creating a tight mechanical and electrical bond without the need for additional tape in most standard installations. The orange color coding helps electricians quickly identify connector size and wire gauge range during installation, reducing the chance of mismatches in the field. This connector is a staple fastener for licensed electricians and experienced DIYers working on branch circuit wiring, fixture connections, and junction box terminations.

Orange wire connectors are commonly used in residential branch circuit wiring, light fixture installations, outlet and switch connections, and junction box work. They are well suited for splicing multiple smaller-gauge conductors in both new construction and retrofit projects. Electricians working on low-voltage and line-voltage circuits reach for color-coded connectors like the W8301 to maintain organized, code-compliant terminations inside enclosures.

Key Features

• Orange color coding for quick size and gauge identification at the worksite
• Twist-on design creates a secure mechanical and electrical connection on stripped conductors
• Insulated shell eliminates the need for additional tape in standard dry-location installs
• Compact form factor fits standard junction boxes and electrical enclosures
• Suitable for residential and light commercial branch circuit terminations

Compatibility

Designed as a standard twist-on wire connector for use in typical residential and light commercial electrical splicing applications where an orange-rated connector size is appropriate.

Installation Notes

Installation should be performed by a licensed electrician or qualified individual in accordance with the National Electrical Code (NEC) and all applicable local codes. Always de-energize the circuit at the breaker and verify absence of voltage with a meter before making or disturbing any connections. Strip conductors to the recommended length, twist conductors together, then thread the connector clockwise until snug with no bare copper visible below the skirt. Never overtighten to the point of cracking the insulated shell.

Technical Specifications

• Weight: 13 pounds
• UPC: 75133830560

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: W8301
