Southwire P40073-1D Thermostat Cable 18/2 Stranded CL2P 500 ft.

Product Description

The Southwire P40073-1D is a low-voltage thermostat cable designed for general use in various applications. This cable is suitable for remote control, signaling, and power-limited circuits. Its applications include security systems, audio, intercom, alarm systems, and access control circuits. Rated for Plenum use and 300V, this cable meets stringent electrical codes.

• 500 feet length for extensive installations
• Plenum-rated for safe in-ceiling routing
• Ideal for security, sound, and alarm system wiring

Product Highlights

The Southwire P40073-1D is engineered for reliable performance in thermostat wiring scenarios.

Product Information

Standard Information

• Wire Type: Thermostat Wire
• Conductor Size: 18 AWG

Technical Specifications

• Length: 500 feet
• Conductors: 2
• Plenum Rated: Yes
• Diameter Over Conductor: 0.045 inch
• Insulation Thickness: 9 mils
• Approx. OD: 0.186 inch
• Copper Weight: 21 lbs/1000'
• DC Resistance at 25C: 6.669 ohms/1000'
• Shipping Weight: 18 pounds
• Shipping Dimensions: 10.80 x 10.80 x 7.00 inches
