Southwire N-200350 Lb Conduit Body 3 Inch Aluminum

Product Description

The SOUTHWIRE N-200350 is a 3-inch aluminum LB type conduit body designed for use with rigid threaded conduit systems. It ships complete with a cover and gasket, allowing for a weathertight assembly straight out of the box. The LB configuration provides a 90-degree pull point with a back-entry and bottom-exit orientation, making it a standard fitting for routing conduit around corners and through walls. Licensed electricians install this type of fitting during commercial and residential conduit runs where accessible pull points and direction changes are required by code.

This fitting is suited for rigid metal conduit installations in both interior and exterior environments. The aluminum construction resists corrosion, making it appropriate for outdoor service entrances, industrial panels, and wet or damp locations. The included cover and gasket maintain the integrity of the enclosure and allow the body to be opened for wire pulling, splicing where permitted by code, or future maintenance access. The 3-inch trade size accommodates large-conductor runs typical in service entrance and feeder applications.

Key Features

• LB configuration provides a 90-degree direction change with back-entry and bottom-exit orientation
• 3-inch trade size for rigid threaded conduit systems
• Aluminum construction offers corrosion resistance for wet, damp, and outdoor locations
• Includes matching cover and gasket for a complete, weathertight installation
• Accessible body design supports wire pulling and future service work

Compatibility

The N-200350 is compatible with 3-inch rigid threaded conduit. It is also referenced as a direct equivalent to Madison LBLA-300 and Topaz LB8CG.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize all circuits before opening or servicing any conduit body. Thread the fitting onto the conduit using appropriate thread-sealing methods for the application and tighten with a conduit wrench. Do not use this fitting as a junction box unless the conductor fill and code requirements for that application are met.

Technical Specifications

• Trade Size: 3 inches
• Configuration: LB Type (90-degree, back-entry, bottom-exit)
• Material: Aluminum
• Conduit Type: Rigid Threaded
• Includes: Cover and Gasket
• UPC: 751338209114

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: N-200350
