Southwire LL9M Type Ll Conduit Body 3.5 Inches Malleable Iron

Product Description

The SOUTHWIRE LL9M is a malleable iron Type LL conduit body designed for use with rigid threaded conduit systems. This fitting provides a left-turn pull point that allows installers to route conductors through 90-degree bends in conduit runs while maintaining access for wire pulling and future maintenance. With a trade size of 3.5 inches, it is built for larger conductor installations common in commercial and industrial electrical work. Licensed electricians and electrical contractors install this fitting as a standard component in rigid conduit systems.

The LL9M is suited for commercial and industrial conduit installations where rigid threaded conduit is specified. It is used in applications requiring a left-lateral body configuration to navigate turns in the conduit run. This conduit body size is commonly found in main feeders, large branch circuits, and service entrance conduit systems where conductor fill and pull access are critical considerations.

Key Features

• Type LL configuration provides a left-lateral 90-degree turn in the conduit run
• 3.5-inch trade size accommodates large-diameter rigid threaded conduit
• Malleable iron construction offers durability in demanding installation environments
• Threaded hubs ensure secure, rigid connection to conduit sections
• Removable cover plate provides access for wire pulling and conductor inspection

Compatibility

Designed as an OEM-style replacement and standard-fit conduit body for 3.5-inch rigid threaded conduit systems. Referenced as a replacement for Madison LLM-350.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize the circuit and verify lockout/tagout procedures before working on any conduit system. Thread all connections fully and apply appropriate thread sealant or thread compound as required for the installation environment. Do not exceed the conductor fill limits specified by NEC Article 314 for conduit bodies.

Technical Specifications

• Trade Size: 3.5 inches
• Body Type: Type LL
• Material: Malleable Iron
• Conduit System: Rigid Threaded
• UPC: 751338212206

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: LL9M
