Southwire LL9CG Rigid Conduit Body

Product Description

The Southwire Rigid Conduit Body, MPN LL9CG, features a design for efficient access to conductors. It facilitates pulling and maintenance tasks without hindrance. This product is suitable for use in various electrical installations.

• Access opening located on the left side
• UL and CSA approved for safety
• Constructed with a durable die-cast copper-free aluminum body

Product Highlights

This conduit body allows easy access to wires and conductors, enhancing operation efficiency during connections and repairs.

Product Information

Standard Information

• Manufacturer: Southwire
• Material: Die-Cast Copper Free Aluminum Body, Neoprene Rubber Gasket

Technical Specifications

• MPN: LL9CG
• Hub Size: 3-1/2 Inch
• Configuration: LL
• Hub Location: 90 Degree
• Cover Type: Stamped Steel
• Access Opening: Left Side
• Installation: Threaded
• Approval: UL, CSA
• Number Of Hubs: 2
• Product UPC: 751338211216
• Used On: Rigid Conduit
• Dimensions: 15.5 IN x 6.171 IN x 5.45 IN
