Southwire LL10M Type Ll Conduit Body 4 Inches

Product Description

The SOUTHWIRE LL10M is a 4-inch malleable iron rigid threaded Type LL conduit body designed for use in commercial and industrial electrical conduit systems. Type LL conduit bodies provide a pull point and directional change in a conduit run, with two conduit entries on the same side and one on the end, forming an LL configuration. This fitting is constructed from malleable iron for durability in demanding installation environments. Licensed electricians and electrical contractors install this fitting as part of rigid metal conduit systems where the conduit run must change direction or where wire pulling access is required.

The LL10M is suited for rigid metal conduit installations in commercial, industrial, and heavy-duty residential applications. The threaded design is compatible with standard rigid conduit threading, allowing secure mechanical and electrical connection within the conduit system. It is commonly installed at corners, wall penetrations, and transition points where conduit changes direction. The 4-inch trade size accommodates larger conductor bundles typical in feeder and branch-circuit runs.

Key Features

• Type LL configuration provides a directional change with accessible pull point for wire installation
• Malleable iron construction offers strength and resistance to mechanical stress in rigid conduit systems
• 4-inch trade size accommodates larger conductor loads in feeder and branch-circuit applications
• Rigid threaded design ensures secure, code-compliant connections to rigid metal conduit
• Compatible with standard rigid conduit threading for straightforward field installation

Compatibility

Designed as an OEM-style replacement and standard fitting for 4-inch rigid metal conduit systems. Input data references Madison LLM-400 as a compatible or equivalent designation.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements for rigid metal conduit systems. De-energize all circuits and verify lockout-tagout procedures are complete before opening or working near any conduit body. Use appropriate pipe wrenches and thread sealant approved for electrical conduit when making threaded connections. Ensure the cover and gasket are properly secured after conductor installation to maintain the required enclosure rating.

Technical Specifications

• Trade Size: 4 inches
• Material: Malleable Iron
• Conduit Body Type: Type LL
• Connection Type: Rigid Threaded
• UPC: 751338212305

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: LL10M
