Southwire Company 22141109 300VAC 18 AWG 1000 ft L Low Voltage Cable

Product Description

The Southwire Company 22141109 is a low voltage cable with a voltage rating of 300VAC. This cable has a wire size of eighteen AWG and is one thousand feet long. It is made of bare stranded copper and designed to meet the requirements for Type CMR/CL2R/FT4 shielded applications.

• Length: 1000 feet
• Wire size: 18 AWG
• Applications: For burglar alarms and intercoms

Product Highlights

This low voltage cable is suitable for various applications including phone and speaker systems.

Product Information

Standard Information

• Brand: Southwire Company
• MPN: 22141109

Technical Specifications

• Type: Type CMR/CL2R/FT4 Shielded
• Outside Diameter: 0.154 inch
• Conductor Material: Bare Stranded Copper
• Number of Conductors: 2
• Jacket Material: PVC
• Jacket Color: Gray
• Temperature Rating: -20 to 60 Deg C
• Applications: For burglar alarm, intercom, phone, and speakers
• Standards/Approvals: UL Standards 13, 444, NEC Articles 725, 800, CSA C22.2 No. 214
