Southwire Company 160M Topaz Straight Cable Angle Connector 4 in 4 in Knockout

Product Description

The Southwire Company 160M Topaz Straight Cable Angle Connector is used for connecting armored and metal clad cables. This connector has a knockout size of four inches and accommodates cable openings from four point zero six to four point four four inches. It is made from malleable iron and has a zinc plated finish to resist corrosion.

• Made from durable malleable iron
• Compatible with MC cables
• Designed for easy installation with two screws

Product Highlights

This connector is suited for both residential and commercial applications where metal clad or armored cable connections are required, ensuring a secure and reliable connection.

Product Information

Standard Information

• Part Number: 160M
• Brand: Southwire Company

Technical Specifications

• Cable Openings: 4.06 to 4.44 in
• Cable Type: MC
• Connection Type: Threaded x Squeeze
• Country of Origin: MUL
• Dimensions: 3.69 in L
• Finish: Zinc Plated
• Knockout Size: 4 in
• Material: Malleable Iron
• Mfg Standards/Approvals: UL 514B, UL File Number 0258 Listed, US Federal Specification Number A-A-50552, NEMA/ANSI FB-1, CSA Certified, Military Specification: W-F-406D, W-F-406E, W-F-408D, W-S-610D, RoHs Compliant
• Number of Conductors: 1
• Package Height: 5.31 in
• Package Length: 7.19 in
• Package Weight: 6.019 lb
• Package Width: 4.75 in
• Trade Size: 4 in
• Type: Straight
