Southwire C4SSCG 1-1/4 in Aluminum C-type Conduit Body

Product Description

The SOUTHWIRE C4SSCG is a 1-1/4 inch C-type conduit body manufactured from corrosion-resistant aluminum, designed for use with EMT and threaded rigid metal conduit installations. The straight-through configuration simplifies conductor pulling and splicing, making it a practical choice for electrical contractors working in both dry and wet environments. The domed cover provides additional interior volume for wire management, and the included gasket maintains a NEMA FB 1 wet-location rating. Smooth, rounded integral bushings in each hub protect conductor insulation during pull-through. Lightweight aluminum construction delivers reliable ground continuity without adding excess weight to the conduit run.

This conduit body is suited for commercial and residential electrical installations where accessible junction or pull points are required along a conduit run. The C-type body allows straight-line wire access, which is especially useful in tight spaces or long pulls. The NEMA FB 1 rating makes it appropriate for exposed outdoor locations or damp interior environments. It is compatible with threaded rigid metal conduit only and is not intended for use as a conduit fitting on EMT without threaded adapters. Licensed electricians performing rough-in and finish electrical work will find this a standard-duty component for 1-1/4 inch conduit systems.

Key Features

• C-type straight-through configuration for simplified wire pulling and splicing
• Corrosion-resistant aluminum construction for long-term durability in wet locations
• NEMA FB 1 rated for wet-location use
• Domed cover increases interior wiring space
• Smooth, rounded integral hub bushings protect conductor insulation
• UL listed

Compatibility

Designed for use with 1-1/4 inch threaded rigid metal conduit systems. Compatible with EMT and rigid combo conduit configurations. For threaded rigid metal conduit use only; EMT requires appropriate threaded adapters.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize all circuits completely before opening or working on any conduit body. Verify that the gasket is properly seated before securing the domed cover to maintain the NEMA FB 1 wet-location rating. Do not overtighten the cover screws, as this may damage the gasket and compromise the environmental seal.

Technical Specifications

• Trade Size: 1-1/4 inches
• Body Type: C-Type
• Material: Aluminum
• Wet Location Rating: NEMA FB 1
• Includes: Cover and Gasket
• Listing: UL Listed
• UPC: 751338837898

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: C4SSCG
